Category |
Parameter |
Specification Details |
|
Truck Name |
FAW Lorry Truck |
|
|
Basic Info |
Vehicle Type |
Medium-Duty Rigid Cargo Truck / Lorry |
|
|
Drive Configuration |
6×2 (Rear Tag/Pusher Axle) or 6×4 (Dual Drive Axles) |
|
|
Common Series Models |
FAW J6L, FAW J6M, FAW JK6 |
|
Weights & Dimensions |
Gross Vehicle Weight (GVW) |
15,000 kg – 25,000 kg (Depends on regional regulations) |
|
|
Max Payload Capacity |
10,000 kg – 18,000 kg |
|
|
Wheelbase |
4,300 mm + 1,350 mm / 4,800 mm + 1,350 mm |
|
|
Cargo Body Length Range |
6,200 mm to 8,600 mm (6.2m – 8.6m) |
|
Powertrain & Engine |
Engine Model Options |
FAWDE (FAW Engine) CA6DF / CA6DL Series |
|
|
Displacement |
6.0L / 6.6L / 7.1L / 8.6L |
|
|
Max Horsepower Output |
220 HP / 240 HP / 280 HP / 320 HP / 350 HP |
|
|
Max Torque |
850 Nm – 1,500 Nm @ 1,200–1,700 RPM |
|
|
Emission Standards |
Euro 3 / Euro 4 / Euro 5 / Euro 6 compliant |
|
Drivetrain |
Transmission Type |
FAST Manual Transmission (8-Speed or 9-Speed) |
|
|
Clutch |
Single-plate, dry diaphragm spring clutch (Hydraulic with air assist) |
|
|
Rear Axle Ratio Options |
3.727 / 4.111 / 4.444 / 4.875 |
|
Chassis & Suspension |
Frame Type |
High-strength steel, straight ladder frame structure |
|
|
Front Suspension |
Semi-elliptic leaf springs with telescopic shock absorbers |
|
|
Rear Suspension |
Heavy-duty leaf springs (Balanced suspension for 6×4) |
|
|
Tire Size |
10.00R20 / 11.00R20 / 295/80R22.5 (Radial tubeless) |
|
Brakes & Safety |
Service Brake |
Dual-circuit pneumatic air brakes |
|
|
Safety Features |
ABS (Anti-lock Braking System), Exhaust Engine Brake (EVB) |
|
Cabin & Fuel |
Cabin Style |
Forward-control Sleeper Cab (1 Bunk, tilting mechanism) |
|
|
Comfort Amenities |
Air-conditioned (A/C), Ergonomic dashboard, AM/FM Radio |
|
|
Fuel Tank Capacity |
300 Liters / 400 Liters (Steel or Aluminum tank) |
The incredible versatility of the FAW Lorry makes it the perfect match for a wide array of industries:Urban Cargo Distribution: Smaller FAW Lorry Truck models excel at navigating tight city streets for retail and e-commerce deliveries.Agricultural Transport: Farmers rely heavily on the FAW Lorry to safely transport crops, livestock, and heavy machinery.Construction Material Hauling: Easily fitted with drop-side bodies or flatbeds, the FAW Lorry Truck is a staple on rugged construction sites.
The global popularity of the FAW Lorry Truck is driven by its exceptional engineering standards and versatile design options:
Fuel-Efficient Engine Options: Every FAW Lorry is equipped with a high-performance engine that delivers high torque at low RPMs, drastically cutting down on fuel consumption.
Robust Chassis Design: Built with high-tensile steel, the chassis of the FAW Lorry handles maximum legal payloads without compromising structural safety.
Versatile Configurations: From light-duty delivery models to heavy-duty multi-axle platforms, there is a FAW Lorry configured for every type of cargo haul.
Exceptional Total Cost of Ownership (TCO)
Fuel and maintenance are the highest ongoing costs for any transportation business. The FAW Lorry is engineered with an aerodynamic cab and a highly optimized fuel injection system. This unique design minimizes fuel burn per kilometer, ensuring that your FAW Lorry Truck boosts your profit margins from day one.
World-Class Driver Comfort and Safety
Long hours on the road require a workspace that minimizes fatigue. The cabin of the modern FAW Lorry features an ergonomic layout, an air-suspended driver’s seat, clear dashboard visibility, and excellent sound insulation. Furthermore, the safety cabin structure of the FAW Lorry Truck meets strict international crash-test safety regulations to protect operators.
For urban last-mile delivery and short-distance cargo transport, the 3-5 ton light-duty Faw Lorry Truck (Tiger V series) is the most popular option. This 4×2 drive light lorry comes with a compact body design, flexible maneuverability, and a horsepower output of less than 150HP, striking a perfect balance between loading capacity and fuel economy. Equipped with Euro 3 emission compliance, it meets most regional environmental regulations for city logistics, while its customizable flatbed or dropside cargo box can easily accommodate general goods, furniture, food, and daily supplies.
