| CHINA FAW GARBAGE COMPACTOR TRUCK | ||||
| Vehicle type | CA3250 | CA3250 | CA3250 | |
| Drive mode | 6×4 | 6×4 | 6×4 | |
| Cab | JH6 Convex floor full-floating flattop | JH6 Convex floor full-floating flattop |
JH6 Convex floor full-floating flattop |
|
| Engine | Model | WeichaiWP10.380E22 | WeichaiWP10H375E50 | FAWDE CA6DM2-42E52 |
| Displacement (L) |
9.7 | 9.5 | 11.05 | |
| Maximum power (hp) |
380 | 375 | 420 | |
| Rated speed (rpm) |
2,200 | 1,900 | 1,900 | |
| Maximum torque/speed (Nm/rpm) |
1460/1200-1600 | 1800/1100-1400 | 2200/1300-1400 | |
| Emission | EUROII | EURO V | EURO V | |
| Transmission | Model | FAST12JSD160T | FAST12JSD180T | FAST12JSDX240TA |
| Form/number of gears |
Manual/12 | Manual/12 | Manual/12 | |
| Forward gear ratio coverage |
15.53-1.0 | 15.53-1.0 | 12.1-0.78 | |
| Front axle load (kg) | 9000 | 9000 | 6,500 | |
| Front suspension | Multiple leaf spring | Multiple leaf spring | Multiple leaf spring | |
| Rear axle load (kg) | 2×16000 | 2×16000 | 2×16000 | |
| Rear suspension | Multiple leaf spring | Multiple leaf spring | Multiple leaf spring | |
| Rear axle model/speed ratio |
φ300/5.921 | φ300/5.263 | φ300/5.921 | |
| Chassis weight (kg) | 10650 | 10680 | 10680 | |
| Towing Weight (kg) | ≤60 | ≤60 | ≤60 | |
| Wheel base (mm) | 3900+1350 | 3800+1350 | 3900+1350 | |
| Saddle | 5600x2300x1400 | 5600x2300x1500 | 5600x2300x1300 | |
| Tire | 12.00R20 | 12.00R20 | 12.00R20 option 13R22.5 | |
| Brake system | Drum brake, optional ABS | Drum brake, optional ABS | Drum brake, ABS, hydraulic retarder |
|
Capacity: Available in configurations with a garbage container volume of 6-24 cubic meters, supporting payloads of 8-18 tons. 4X2 and 6X4 models are available to adapt to narrow urban streets and long-haul waste transport needs.
Compression System: Equipped with a high-power hydraulic system that achieves a compression ratio of 3:1 to 5:1, effectively reducing waste volume and increasing transport efficiency. The system supports one-button operation for automatic loading, compression, and unloading.
Engine & Transmission: Powered by a FAW CA6DL2 series diesel engine (240-350 hp) that meets Euro III/Euro V emission standards. Paired with a 6-speed manual or automatic transmission for stable performance and fuel efficiency.
Sealed Container Structure: The garbage container is made of high-strength steel with a fully sealed design to prevent leakage and odor emission during transport. Optional stainless steel inner walls offer exceptional resistance to corrosion and wear.
Multi-Loading Modes: Supports rear loading (manual or automatic hopper), side loading (hydraulic arm for 240L bins), and top loading for bulky waste. The hydraulic arm can lift up to 200 kg and operates within 10-15 seconds per bin.
Compliance: Meets international standards including ISO 9001, CCC, and CE, ensuring compliance with regulations in China, Southeast Asia, Africa, and South America.
Warranty & Support: Offers a 1-year or 100,000 km warranty on key components such as the engine, hydraulic system, and container. FAW Jiefang’s global service network provides prompt technical support and spare parts supply.
