| Category | Specification Details |
|---|---|
| Truck Name | FAW J7 8X4 Cargo Truck |
| Basic Information | – Model: CA1320P77K24L7T4E6 – Drive Type: 8X4 – Condition: New – Certification: ISO9001, CCC, CE, Euro VI, EAC, OTTC |
| Dimensions & Weight | – Wheelbase: 1800+3000+1350mm – Overall Length: 12.0m – Width: 2.55m – Height: 3.9m – Tare Weight: 8.9 tons – GVW: 32 tons – Max Hauling Capacity: 43 tons |
| Engine | – Brand: Xichai – Model: CA6DM3-56E61 – Type: Inline 6-Cylinder Diesel – Displacement: 12.52L – Horsepower: 560 HP (Optional: 460-530 HP) – Max Torque: 2600 N·m – Emission Standard: Euro VI |
| Transmission | – Type: ZF 12-Speed Automated Manual (AMT) – Gear Ratios: 12 Forward + 2 Reverse – Features: Hydraulic Retarder, Automatic Shift Control |
| Chassis & Suspension | – Front Axle Load: 7000 kg – Rear Axle Load: 18000 kg – Rear Axle Type: Φ457 Differential Lock Axle – Suspension: Multi-leaf Spring – Tire Specification: 295/80R22.5 (10 tires + 1 spare) |
| Cab | – Type: High-Roof Full-Floating Cab (J7H) – Seating: 3 Persons – Features: Air-Suspension Driver Seat, Multi-Zone AC, Noise-Canceling System |
| Safety Features | – Anti-lock Braking System (ABS) – Electronic Stability Control (ESC) – 360° Surround View Camera – Lane Departure Warning, Collision Mitigation |
| Fuel & Efficiency | – Fuel Tank Capacity: 1000L – Maximum Speed: 110 km/h – Optimal Fuel Economy Speed: 70-90 km/h |
| Electrical System | – Voltage: 24V – Battery Capacity: 200Ah |
| Warranty | – 1 Year or 100,000 km (whichever comes first) |
The FAW J7 8X4 Cargo Truck features an ultra-lightweight construction that has been optimized without compromising strength or durability. The FAW J7 8X4 Cargo Truck uses high-strength steel for its chassis, which reduces weight by 300 kg compared to traditional steel frames, while maintaining the same level of structural integrity. Additionally, the FAW J7 8X4 Cargo Truck comes equipped with aluminum alloy wheels, air suspension systems, and a composite fuel tank, further reducing vehicle weight and improving fuel efficiency.
Under the hood, the FAW J7 8X4 Cargo Truck is powered by a high-performance Xichai CA6DM3-46E6 engine, which delivers an impressive 460 horsepower and 2300 N·m of torque. This powerful engine, combined with a 12-speed automated manual transmission (AMT) from FAW, provides the FAW J7 8X4 Cargo Truck with exceptional acceleration and climbing ability, even when fully loaded. The FAW J7 8X4 Cargo Truck also features a small rear axle ratio of 3.727, which allows it to maintain a constant speed of 85 km/h at just 1100 rpm, reducing engine wear and improving fuel efficiency.
The FAW J7 8X4 Cargo Truck is equipped with a range of intelligent features that make it a fully connected vehicle for modern green transport operations. The FAW J7 8X4 Cargo Truck features a 12-inch touchscreen display that integrates navigation, entertainment, and vehicle diagnostic functions, providing drivers with all the information they need at their fingertips. The FAW J7 8X4 Cargo Truck also comes equipped with a telematics system that allows fleet managers to monitor vehicle performance, fuel consumption, and driver behavior in real-time, enabling them to optimize routes, reduce costs, and improve safety.
The FAW J7 8X4 Cargo Truck features a spacious, ergonomic cab that has been designed with driver comfort and productivity in mind. The FAW J7 8X4 Cargo Truck features a high-roof cab with a standing height of 2.1 meters, providing ample headroom and space for drivers to move around. The FAW J7 8X4 Cargo Truck also comes equipped with a fully adjustable air suspension seat from Grammer, which provides exceptional comfort even on rough roads, reducing driver fatigue during long shifts.
