FAW JK6 4×2 5 Ton Rigid Truck
In the fast-paced world of city logistics and regional distribution, the FAW JK6 4x2 5 Ton Rigid Truck stands out as a versatile and high-efficiency workhorse.
Engineered by FAW Jiefang to bridge the gap between light-duty vans and heavy haulers, the FAW JK6 4x2 5 Ton Rigid Truck offers the perfect combination of payload capacity, maneuverability, and low operating costs.
FAW JK6 4x2 5 Ton Rigid Truck: The Ultimate Urban Delivery Solution
TECHNICAL DATA
| Category | Specification Details |
|---|---|
| Truck Name | FAW JK6 4×2 5 ton Rigid Truck |
| Basic Information | – Model: CA1080P40K2L5E5A84 – Drive Type: 4X2 – Condition: New – Certification: ISO9001, CCC, CE, Euro V, EAC |
| Dimensions & Weight | – Wheelbase: 3600mm – Overall Length: 5.995m – Width: 2.45m – Height: 3.2m – Tare Weight: 3.49 tons – GVW: 8 tons – Max Payload: 5 tons |
| Engine | – Brand: Weichai – Model: WP3.7Q130E50 – Type: Inline 4-Cylinder Diesel – Displacement: 3.66L – Horsepower: 130 HP – Max Torque: 450 N·m – Emission Standard: Euro V |
| Transmission | – Type: WLY 6TS40 Manual – Gear Ratios: 6 Forward + 1 Reverse – Features: Hydraulic Clutch, Synchronized Gearbox |
| Chassis & Suspension | – Front Axle Load: 3 tons – Rear Axle Load: 5 tons – Rear Axle Type: Qingte 1068 Casting Axle – Suspension: Leaf Spring Suspension – Tire Specification: 7.50R16-14PR (6 tires + 1 spare) |
| Cab | – Type: Tiger VH Single Row Cab – Seating: 2 Persons – Features: Air Conditioning, Adjustable Steering Wheel |
| Safety Features | – Anti-lock Braking System (ABS) – Airbags – Reversing Camera – Tire Pressure Monitoring System |
| Fuel & Efficiency | – Fuel Tank Capacity: 150L (Aluminum) – Maximum Speed: 100 km/h – Optimal Fuel Economy Speed: 60-80 km/h |
| Electrical System | – Voltage: 24V – Battery Capacity: 120Ah |
| Warranty | – 1 Year or 100,000 km (whichever comes first) |
FEATURES AND BENEFITS
FAW JK6 4×2 5 Ton Rigid Truck: High-Efficiency Powertrain
The FAW JK6 4×2 5 Ton Rigid Truck is powered by the advanced CA4DK or CA4D engine series, delivering between 160HP and 220HP. This engine is specifically tuned for the “stop-and-go” nature of urban traffic, providing high torque at low RPMs to ensure quick acceleration even when fully loaded. Paired with a smooth 6-speed or 8-speed manual transmission, the FAW JK6 4×2 5 Ton Rigid Truck achieves industry-leading fuel economy, significantly reducing your total cost of ownership (TCO).
FAW JK6 4×2 5 Ton Rigid Truck: Optimized for Urban Maneuverability
Navigating narrow city streets and crowded loading docks is effortless with the FAW JK6 4×2 5 Ton Rigid Truck. Its 4×2 chassis configuration and optimized steering geometry provide a tight turning radius, making it more agile than larger rigid trucks. With a Gross Vehicle Weight (GVW) typically ranging from 10 to 12 tons, the FAW JK6 4×2 5 Ton Rigid Truck is the ideal 5-ton payload carrier for “last-mile” express delivery and supermarket supply chains.
Versatile Cargo Body Options
The chassis of the FAW JK6 4x2 5 Ton Rigid Truck is designed for maximum adaptability.
FAW JK6 4×2 5 Ton Rigid Truck: Driver Comfort and Safety
Despite its role as a rugged delivery tool, the FAW JK6 4×2 5 Ton Rigid Truck features a modern, ergonomic cabin. The interior includes:
- Air-Suspension Seats: Reducing driver fatigue during long shifts.
- Wide Vision Windshield: Enhancing safety in busy pedestrian areas.
- Advanced Braking Systems: Equipped with ABS for reliable stopping power in all weather conditions.
Key Features
Drivability
Fuel Efficiency
Safety
Productivity
Uptime
