| Category | Specification Details |
|---|---|
| Truck Name | FAW JK6 4×2 5 ton Rigid Truck |
| Basic Information | – Model: CA1080P40K2L5E5A84 – Drive Type: 4X2 – Condition: New – Certification: ISO9001, CCC, CE, Euro V, EAC |
| Dimensions & Weight | – Wheelbase: 3600mm – Overall Length: 5.995m – Width: 2.45m – Height: 3.2m – Tare Weight: 3.49 tons – GVW: 8 tons – Max Payload: 5 tons |
| Engine | – Brand: Weichai – Model: WP3.7Q130E50 – Type: Inline 4-Cylinder Diesel – Displacement: 3.66L – Horsepower: 130 HP – Max Torque: 450 N·m – Emission Standard: Euro V |
| Transmission | – Type: WLY 6TS40 Manual – Gear Ratios: 6 Forward + 1 Reverse – Features: Hydraulic Clutch, Synchronized Gearbox |
| Chassis & Suspension | – Front Axle Load: 3 tons – Rear Axle Load: 5 tons – Rear Axle Type: Qingte 1068 Casting Axle – Suspension: Leaf Spring Suspension – Tire Specification: 7.50R16-14PR (6 tires + 1 spare) |
| Cab | – Type: Tiger VH Single Row Cab – Seating: 2 Persons – Features: Air Conditioning, Adjustable Steering Wheel |
| Safety Features | – Anti-lock Braking System (ABS) – Airbags – Reversing Camera – Tire Pressure Monitoring System |
| Fuel & Efficiency | – Fuel Tank Capacity: 150L (Aluminum) – Maximum Speed: 100 km/h – Optimal Fuel Economy Speed: 60-80 km/h |
| Electrical System | – Voltage: 24V – Battery Capacity: 120Ah |
| Warranty | – 1 Year or 100,000 km (whichever comes first) |
