FAW JH6 Electric Tractor Truck
TECHNICAL DATA
| FAW JH6 ELECTRIC TRACTOR TRUCK | |
| Model Number (Notification): | CA4259P26T1BEVA80 |
| Front Track/Rear Track: | Front track: 2020mm; Rear track: 1830/1830mm |
| Country of Origin: | Qingdao, Shandong |
| Drive Type: | 6X4 |
| Wheelbase: | 3800+1350mm |
| Vehicle Length: | 7.36 meters |
| Vehicle Width: | 2.55 meters |
| Vehicle Height: | 3.5 meters |
| Curb Weight: | 11 tons |
| Gross Vehicle Weight: | 25 tons |
| Maximum Speed: | 89km/h |
| Remarks: | Fast 6E240 |
| Towing Capacity: | 37.87 tons |
| Tonnage Class: | Heavy truck |
| Market Segment: | Short-distance transportation to railway stations, steel mills, and ore powder storage yards |
| CLTC Driving Range: | 220km |
| Energy Type: | pure electric |
| Battery Swapping Support: | charging |
| Motor Model 1: | CAM400PT52 |
| Motor Type: | Permanent magnet synchronous motor |
| Total Rated Power: | 270kW |
| Peak Power: | 420kW |
| Fuel Type: | Pure electric |
| Number of Drive Motors: | Single motor |
FAW JH6 ELECTRIC TRACTOR TRUCK
Electric Motor: Equipped with a high-torque permanent magnet synchronous electric motor, typically delivering up to 400kW (536HP) of power and maximum torque of 2500N·m. This direct-drive electric motor provides instant torque for heavy-load hauling and rough terrain operation, eliminating the need for complex transmission systems.
Battery System: Powered by a high-capacity lithium-ion phosphate battery pack with energy storage typically ranging from 282-350kWh. The battery system supports fast charging capability, allowing for 80% charge in just 1.5 hours using a high-power DC charger, ensuring minimal downtime during operation.
Range and Efficiency: Offers a working range of up to 200km on a single charge under typical operating conditions, with regenerative braking system that recovers energy during downhill driving and deceleration to extend range and improve overall efficiency.
.
FAW JH6 ELECTRIC TRACTOR TRUCK
Traction Capacity: Offers a maximum traction weight of up to 70-80 tons, making it suitable for heavy-duty long-haul transport operations. The truck is built on a reinforced JH6 heavy-duty chassis with a wheelbase of 3300+1350mm, ensuring stability and durability for extended journeys.
Chassis & Suspension: Constructed with a heavy-duty steel chassis frame and reinforced leaf spring suspension system, designed to withstand the rigors of constant loading, unloading, and long-distance highway operation. The truck is equipped with 315/80R22.5 tubeless radial tires for reliable performance on diverse road surfaces.
Braking System: Advanced safety features including anti-lock braking systems (ABS), electronic stability control (ESC), and regenerative braking system ensure enhanced stability and safety during operation. The truck also features dual-circuit compressed air brakes for reliable stopping power in all weather conditions.
FAW JH6 ELECTRIC TRACTOR TRUCK
Ergonomics: The JH6 features a spacious high-roof cabin with an ergonomic dashboard layout, designed to reduce driver fatigue during long shifts and improve visibility on highways. The cabin is equipped with multi-function steering wheel, air-suspension seat with lumbar support, and automatic climate control for enhanced comfort.
Convenience: Standard equipment includes a high-resolution digital instrument cluster displaying battery status, range, and charging information, an infotainment system with Bluetooth connectivity, and electric cabin lifting for easy maintenance access.
