Faw 3 Axles Flatbed Semi Trailer

1. Super Reinforced Load-Bearing Structure

Main I-beam adopts 500mm high three-layer composite plate (upper 20mm + web 12mm + bottom 20mm), automatic submerged arc welding integrated molding, pre-camber technology to prevent chassis sagging under full load. The 3mm thick anti-slip checkered steel platform bears uniform pressure and resists abrasion.

2. 3-Axle Balanced Load Distribution

Three 13-ton heavy-duty FUWA/BPW axles evenly disperse cargo weight, effectively reduce tire wear and improve highway driving stability; optional mechanical leaf spring suspension or air suspension for different road conditions.

3. Complete Standard Safety Configuration

a. JOST 2/3.5 inch bolted kingpin, strong connection with FAW tractor head
b. 28-ton double-speed landing gear, stable support during cargo loading/unloading
c. Dual air drum brake system with WABCO relay valve; ABS anti-lock system optional
d. 12 sets container twist locks for fixed container transport; multiple lashing rings for binding bulk goods
e. Full 24V LED lighting system with rear reflective warning strips and anti-collision bumper

4. Low Operation & Maintenance Cost

All wearing parts adopt globally universal mainstream brands, easy access to spare parts worldwide; zinc-rich primer + polyurethane topcoat double anti-rust treatment, 5+ years anti-corrosion service life.

5. Full Customization Support

Adjustable overall length (20ft / 40ft / 45ft), payload capacity, paint color, tire specifications and accessory sets according to customer local transport regulations and cargo demands.
