FAW J6P Cargo Truck
TECHNICAL DATA
| FAW JIEFANG J6P CARGO TRUCK | |
| Model Number: | CA5310XXYP66K24L7T4E6 |
| Type: | Box truck |
| Drive Type: | 8X4 |
| Wheelbase: | 2100+4500+1350mm |
| Box Length Class: | 9.5 meters |
| Engine: | CA6DM2-46E6 |
| Transmission: | CA12TAX230M |
| Rear Axle Ratio: | 3.727 |
| Vehicle Length: | 12 meters |
| Vehicle Width: | 2.55 meters |
| Vehicle Height: | 4 meters |
| Front Track: | 2050/2050mm |
| Rear Track: | 1878mm |
| Current Weight: | 13.05 tons |
| Rated Payload: | 18.605 tons |
| Gross Vehicle Weight: | 31 tons |
| Maximum Speed: | 105km/h |
| Country of Origin: | Changchun/Qingdao/Chengdu |
| Tonnage Class: | Heavy-duty trucks |
| Approach Angle: | 15 degrees (°) |
| Departure Angle: | 10 degrees (°) |
| Notes: | 100,000 km long oil change interval |
| Front/Rear Suspension: | 1.5/2.55 meters |
FAW JIEFANG J6P CARGO TRUCK
350HP Configuration: Equipped with Xichai CA6DM2 engine, delivering 350 horsepower and peak torque of 1500 Nm. Paired with a 12-speed manual transmission for precise control.
390HP Configuration: Powered by Xichai CA6DM2-39E3 engine, featuring 6 cylinders, 11.04L displacement, and peak torque of 1750 Nm. Meets Euro 3 emission standards.
420HP Configuration: Utilizes Xichai CA6DM2-42E51 engine with 420 horsepower, paired with FAW Jiefang CA12TAX210M 12-speed manual transmission. Offers a maximum traction weight of up to 40 tons.
460HP Configuration: Features a high-output engine delivering 460 horsepower, paired with advanced transmission options for enhanced performance and fuel efficiency.
FAW JIEFANG J6P CARGO TRUCK
Drivetrain: Features a robust 6×4 drive configuration with dual reinforced rear axles, providing exceptional load distribution and traction for heavy-duty transport. Rear axle ratio options include 4.111 for optimized fuel efficiency and performance.
Chassis: Built on a heavy-duty steel chassis with a wheelbase of 3450+1350mm, ensuring stability and durability for long-haul operations. Equipped with 12.00R20 or 11.00R20 radial tires for reliable performance on various road surfaces.
Fuel System: Configured with a 400L aluminum fuel tank for extended range between refueling stops. Optional natural gas (LNG/CNG) powertrain available with 12.5L engine, delivering 480 or 560 horsepower for eco-friendly operations.
Cargo Capacity: Offers a versatile load capacity ranging from 11 tons to 50 tons, depending on the specific configuration. The truck can be equipped with various body types, including box, flatbed, and curtain-side, to suit different cargo transport needs. The body length ranges from 5.8 meters to 9.5 meters, providing ample space for transporting a wide range of goods.
FAW J6P CARGO TRUCK: Advanced Cargo Body Design
The Faw Jiefang J6p Cargo Truck comes with customizable cargo box options to suit your specific industry needs. From the classic rectangular box for general construction to the reinforced U-shaped body for easy material discharge in mining, every Faw Jiefang J6p Cargo Truck is built with high-wear-resistant steel. The hydraulic lifting system is globally recognized for its stability and fast cycle times, increasing your daily productivity.
