Jiefang Tiger 6g Pure Electric Light Truck
TECHNICAL DATA
| JIEFANG TIGER 6G PURE ELECTRIC LIGHT TRUCK | |
| Model: | CA5048XXYP40L2BEVA85 |
| Type: | Box Truck |
| Drive Configuration: | 4×2 |
| Wheelbase: | 3300 mm |
| Cargo Box Length Class: | 4.2 m |
| Vehicle Length: | 5.995 m |
| Vehicle Width: | 2.2 m |
| Vehicle Height: | 3.31 m |
| Gross Vehicle Weight (GVW): | 4.495 t |
| Rated Payload: | 1.15 t |
| Curb Weight: | 3.15 t |
| Top Speed: | 90 km/h |
| CLTC Range: | 480 km |
| Tonnage Class: | Light-duty truck |
| Energy Type: | Battery Electric (BEV) |
| Forward Gears: | 2-speed |
| Reverse Gears: | 1 |
| Gear Shifting Method: | Automatic (AT) |
| Transmission Model: | Rotary gear selector (fixed gear ratio) |
| Motor 1 Brand: | FAW Jiefang |
| Motor 1 Model: | CAM230PT52 |
| Motor Type: | Permanent magnet synchronous motor |
| Total Rated Power: | 68 kW |
| Peak Power: | 147 kW |
| Total Peak Torque: | 350 N·m |
| Battery Brand: | CATL |
| Battery Type: | Lithium iron phosphate (LFP) battery |
| Battery Capacity: | 100.46 kWh |
| Charging Method: | Fast charging |
| Fast Charging Time: | 1 h |
| Cargo Box Type: | Box-type |
| Cargo Box Length: | 4.16 m |
| Cargo Box Width: | 2.1 m |
| Cargo Box Height: | 2.3 m |
| Cargo Box Volume: | 20 m³ |
| Cargo Box Material: | 0.8 mm thick galvanized steel, anti-corrosion |
🔋 Core Technical Parameters & Performance
It is equipped with a 100.46kWh high-capacity lithium iron phosphate power battery, which supports both conventional AC slow charging and DC fast charging, and meets the needs of multi-scenario charging at logistics parks and public charging stations.
It is matched with a permanent magnet synchronous drive system with a peak power of 147kW, and the CLTC cruising range reaches 350km on a full charge, which can fully cover the daily operating mileage of most urban distribution routes and effectively alleviate range anxiety.
The total mass of the whole vehicle is 4.495 tons, which meets the tonnage standard of domestic light-duty trucks, and the wheelbase is 3300mm, which balances the maneuverability in urban narrow roads and the carrying capacity of cargo.
The 4.16-meter-long enclosed box cargo body can completely isolate cargo from wind, rain and external pollution, which is very suitable for the transportation of express parcels, daily groceries, electronic products, frozen fresh food and other goods that require environmental protection and safety protection.
As a pure electric new energy light truck, its overall size fully complies with urban traffic access restrictions, and can apply for a green truck pass in most Chinese cities, realizing unrestricted passage in core urban areas during traffic control periods, which is very suitable for long-term stable distribution business.
The single-row cab adopts an ergonomic design, with comfortable seating space and clear driving vision, which can reduce driver fatigue during long hours of distribution work.
